EN 818-2 Grade 80 Chain

Buy Online →

General Description

Zintaş Grade 80 Chain: The Solution Combining Strength and Safety

Zintaş is a brand that delivers excellent performance and safety in lifting applications. Grade 80 chains, made with special alloy steel and advanced heat treatment processes, excel in heavy lifting operations.

  • High Strength and Safety: The Grade 80 series from Zintaş Chain meets safety standards with its superior tensile strength compared to ordinary steel chains.
  • Durability and Longevity: Advanced heat treatment processes enhance the durability and longevity of Zintaş Chain.
  • Various Application Areas: Suitable for various industries such as construction, transportation, mining, and industrial lifting.
  • Safety and Quality Standards: Zintaş Chain offers a reliable and high-quality product, fully compliant with international safety standards. Every link provided to the customer has passed all quality and testing processes.

Execute your heavy lifting tasks safely and with long-lasting performance using Zintaş Grade 80 Chain.

Technical Description

Nominal Diameter and Tolerance  Internal Length and Tolerance Internal Width Extarnal Width Weight Working Load Test Load Breaking Load

d  t  bi  ba  Kg/m kN Max.  kN Max.  kN Min.
4 ±0,16 12 ±0,4 5,2 14,8 0,35 500 12,6 20,1
 5 ±0,20 15 ±0,4 6,5 18,5 0,5 800 19,6 31,4
6 ±0,24 18 ±0,5 7,8 22,2 0,8 1120 28,3 45,2
7 ±0,28 21 ±0,6 9,1 25,9 1,1 1500 38,5 61,6
8 ±0,32 24 ±0,7 10,4 29,6 1,4 2000 50,3 80,4
10 ±0,4 30 ±0,9 13 37 2,2 3150 78,5 126
13 ±0,52 39 ±1,2 16,9 48,1 3,8 5300 133 212
16 ±0,64 48 ±1,4 20,8 59,2 5,7 8000 201 322
18 ±0,90 54 ±1,6 23,4 66,6 7,3 10000 254 407
19 ±1,0 57 ±1,7 24,7 70,3 8,1 11200 284 454
20 ±1,0 60 ±1,8 26 74 9 12500 314 503
22 ±1,1 66 ±2,0 28,6 81,4 10,9 15000 380 608
23 ±1,2 69 ±2,1 29,9 85,1 12 16000 415 665
25 ±1,3 75 ±2,2 32,5 92,5 14,1 20000 419 785
26 ±1,3 78 ±2,3 33,8 96,2 15,2 21200 531 849
28 ±1,4 84 ±2,5 36,4 104 17,6 25000 616 985
32 ±1,6 96 ±2,9 41,6 118 23 31500 804 1290
36 ±1,8 108 ±3,0  46,8 133 29 40000 1020 1630
40 ±2,0 120 ±4,0  52 148 36 50000 1260 2010
45 ±2,3 135 ±4,0  58,5 167 45,5 63000 1590 2540

Special Description

USAGE CONDITIONS
Zintaş Grade 80 Chains will experience a reduction in load capacity, as shown in the table, when used at high temperatures.
Temperature Below 200°C Between 200°C and 300°C Between 300°C and 380°C Above 380°C
Load Capacity 100% 90% 75% Not Recommended for Use
Use in chemical and abrasive conditions can alter the load capacity. Chains should not be used in acidic environments.
